Model |
TT5212 |
Frequency Response | HF:60Hz~18KHz MF:200Hz~2KHz LF:60Hz~500Hz |
Component | HF:2x1.5"(3"voice coil), MF:1x10"(3"voice coil) LF:2x12"(4"voice coil), |
Rated Power |
HF:150W AES MF:300W AES LF:1000W AES |
Recommended Amplifier | Three-way power amplifier |
Sensitivity | HF:105dB MF:99dB LF:96dB |
Maximum SPL | 129dB |
Nominal Impedance | 8 ohms |
Dispersion | 120°Hx10°V |
Crossover | 400H;2KHz |
Enclosure | Birch plywood |
Finish | Black ,scrath paint |
Grill | Steel grill with black foam |
Enclosure protection class | IP45(Optional) |
Connector | 2xNeutrik NL 8 |
Dimension(HWD) | 358x950x573mm |
N.W. | 53kg |
