Model |
TT5206 |
Frequency Response | 100Hz~18KHz |
Component | LF:2x6.5"(1.4"voice coil), HF:1x1.75"(1"voice coil) |
Rated Power |
200W AES |
Recommended Amplifier | 400W into 8ohms |
Sensitivity | 94dB |
Maximum SPL | 120dB/1m |
Nominal Impedance | 16 ohms |
Dispersion | 90°Hx10°V |
Enclosure | Birch plywood |
Finish | Black ,scrath paint |
Grill | Steel grill with black foam |
Enclosure protection class | IP45(Optional) |
Connector | 2xNeutrik NL 4 |
Dimension(HWD) | 200x600x285mm |
N.W. | 14.2kg |
